Hydraulic Radio Remote Control Vessel Grab Crane Handling Equipment Remote Control Grab
Product description
OUCO remote control grab bucket whose transmitter can be operated up to a max distance of 100 meter from the grab, which is fitted with remote control receiver. The grab can be operated approx 30 days before the batteries need to be charged.
Features And Advantages
1. The wireless remote control grab can be attached on to the hook of any kind of crane and the handling of the load can be started.
2. The radio controlled grab works with a cylinder and circulation of oil.
3. The radio controlled grab is operated with a battery and a remote control unit, without any requirement for a motor, electricity etc. It does not require cable winding system.
4. operation range:≤100M
5. Equipped with high-capacity battery, the radio controlled grab can work 100 hours without changing the battery.
6. we have designed new hydraulic system for it, which will be less shake and less harm to crane. which is more stable than before.
7. Service of GBM Wireless Remote Control Grab International Warranty Services.
Technical Specification
| Model | OUCO-RC-00 |
| Lifting Weight (t) | 12.5 | 16 | 16 | 16 | 16 | 20 | 25 | 25 | 32 | 40 | 50 |
| Grab Weight (t) | 7.2 | 7.2 | 8.03 | 6.40 | 6.87 | 8.3 | 10 | 15.1 | 14.0 | 16.9 | 21.0 |
| Grab Volume (m³) | 7.8 | 2.8 | 3.1 | 5.05 | 9 | 11.5 | 16.6 | 5 | 22.5 | 23.1 | 23.2 |
| Load Capacity(t) | 5.4 | 9.0 | 8.0 | 9.5 | 9.0 | 11.7 | 15 | 9.9 | 18.0 | 33.1 | 29.0 |
| Fulls | 3 | 5 | 5 | 4 | 3 | 4 | 4 | 3 | 3 | 3 | 3 |
| A(m) | 2.60 | 1.58 | 1.76 | 2.30 | 2.19 | 3.19 | 3.46 | 2.30 | 4.00 | 4.02 | 4.36 |
| B(m) | 3.30 | 2.80 | 2.72 | 2.83 | 3.20 | 3.18 | 3.66 | 3.29 | 3.98 | 4.01 | 4.33 |
| C(m) | 3.91 | 3.33 | 3.36 | 3.78 | 4.29 | 4.34 | 4.90 | 4.07 | 5.34 | 5.48 | 5.90 |
| D(m) | 4.90 | 4.32 | 4.58 | 4.26 | 4.94 | 4.91 | 5.42 | 5.16 | 5.76 | 7.21 | 8.07 |
| E(m) | 4.15 | 3.62 | 3.68 | 3.88 | 4.32 | 4.37 | 4.86 | 4.66 | 5.04 | 6.18 | 6.96 |
| Wire Rope Diameter Φ(mm) | 23.5 | 25.5 | 25.5 | 26 | 25.5 | 28 | 32.5 | 36.5 | 36 | 43 | 46 |
| Pulley Diamrter Φ(mm) | 600 | 700 | 600 | 600 | 600 | 640 | 710 | 930 | 710 | 1120 | 1210 |
General Arrangement
Customer Bulid
Product Images
Packing & Shipping
FAQ
1. What's the information should I provide when inquiry?
More details or drawings, better.
A: Lift capacity B: span C: lift height D: power sourceor other specials you give us will be more appreciated.
2. How many operating methods for my selection?
Standard operating methods:
A: pendent controller with push buttons .B: remote control with push buttons
C: cabin(space capsule seat) control with joystick. Choose any type as you like.
3. Can this type work in hazardous environment?
Sure! We can customize for you, acid proof or explosion proof, no problem for that.
4. Can you provide the serious lifting tools?
Sure, we can provide any lift tools such as lift sling belt, lift clamp, grab, magnet or other specials as your requirement!
5. How can we install the crane?
Our senior engineer can be your side to do the installation guide service and training. Moreover, our best sales can visit your country.
6. Safety device
Overload limiter, Limit Switch (lifting and traveling), Interlock protection device.
For more details, please feel free to contact me as below:
