Marine vessel telescopic hydraulic crane with international brand components
Product description:
The telescopic series of cranes offer a diverse product line for application in the Luxury Yacht, Oceanographic, Workboat, Oilfield, Coast Guard or Military industries. These cranes can also be further customized for use in these most demanding of work environments.
The 3T30M Telescopic boom crane is the first marine crane OUCO has shipped to South America. This crane is available from 3–30 meters of crane boom, which have long range of usage.
Service system: Engineers available to service machinery overseas
Warranty period: 1 year
Certificate:ABS/CCS/ISO9001/BV
General Arrangement:
Technial Specification:
| SWL | 3T@30M&30T6M |
| MAX WORKING RADIUS | 30m |
| MIN WORKING RADIUS | 3m |
| HOISTING SPEED | 0~15m/min |
| HOISTING HEIGHT | 35m |
| SLEWING SPEED | ~0.6r/min |
| SLEWING ANGLE | 360° |
| LUFFING TIME | ~ 90s |
| WORKING CONDITION | TRIM ≤2°
HEEL ≤5° |
| ELEC-MOTOR POWER | Y160L-4-H |
| POWER | 90kw |
| Speed | 1780r/min |
| POWER RESOURCE | AC440V/60HZ |
| PROTECT CLASS | IP44 |
| INSUKATE CLASS | F |
| WORKING TYPE | S1 |
| SELF WEIGHT | 22t |
Production process at OUCO workshop:
Our Certificate:
With years of experience, the OUCO Marine Group has its own designing team and manufacturing factory, excellent European management who has 47 years of experience on offshore business, which also provides after sales services overseas.
Our production line covers marine and offshore knuckle boom crane, telescopic crane, stiff boom crane, non-standard steel structure, more environmental-friendly operations and also truck crane with the range from 15t to 150t.Port industry which includes cranes, hoppers and grabs.
OUCO Machinery can build any type of handling equipment, according to our own design, but also according to provided designs.
We build products according to any certification requested by the client and are able to build them for working in, and under extreme heavy circumstances for working tempertures of - 40C accordingly.
FAQ:
Q: What’s working radius of your crane?
A: From 1m to 100m, we can design and make according to your requirement.
Q: Which crane type should I choose?
A: We have foldable boom, knuckle boom, telescopic boom, stiff boom, etc.
Q: Can this crane be explosion proof?
A: Sure, we can equip any extra function based on your requirement.
Q: Does your crane have safety devices?
A: Of course, we have all cut off limits and alarms for safety reasons.
Q: How can I install the crane to my vessel?
A: We can send our service engineers to the vessel site for guiding or ship the crane in whole piece.
Anything else? We will be pleased to answer all your questions and doubts.
